执行标准CLASSIFICATION | |||||||||||||||||||
符合GB/T10045 T55 4 T1 1 C1 A N5 相当 AWS A5.29 E81T1 Ni2 C ISO 17632-B-T55 4 T1-1 C1 A-N5 | |||||||||||||||||||
产品特性DESCRIPTION | |||||||||||||||||||
SWE81Ni2,相较于SWE81Ni1具有更优的低温强度及韧性，-50℃低温环境仍具有良好的焊接性能及冲击韧性。 适用于Q550D、桥梁S550QL及ASTM A514等同级别钢材。 Compared with SWE81Ni1, SWE81Ni2 has better low-temperature strength and toughness, and still maintains good welding performance and impact toughness in a low-temperature environment of -50℃. It is suitable for steels of the same grade such as Q550D, bridge steel S550QL and ASTM A514. | |||||||||||||||||||
应用APPLICATIONS | |||||||||||||||||||
适用于550MPa级高强钢结构的焊接，多用于船舶、机械制造、容器、石油化工、桥梁、海洋平台等钢结构的焊接。 It is suitable for welding 550MPa-grade high-strength steel structures, and is mostly used for welding steel structures in fields such as shipbuilding, machinery manufacturing, pressure vessels, petrochemical industry, bridges, and offshore platforms. | |||||||||||||||||||
电源类型CURRENT TYPE | 焊枪接正电极DC+ | 过程保护PROCESS | 二氧化碳气保焊100%Co2 Gas-shielded welding | ||||||||||||||||
焊接位置WELDING POSITIONS | 平焊、角焊、仰焊、立向上焊、立向下焊 Flat, fillet, tilt, vertical up , vertical down | ||||||||||||||||||
熔敷金属化学成分CHEMICAL COMPOSITION OF WELDED METAL % | |||||||||||||||||||
项目 | C | Si | Mn | P | S | Ni | |||||||||||||
GB/T Standard | ≤0.12 | ≤0.80 | ≤1.75 | ≤0.03 | ≤0.03 | 1.75-2.75 | |||||||||||||
例值 Typical values | 0.05 | 0.35 | 1.30 | 0.017 | 0.008 | 2.20 | |||||||||||||
熔敷金属力学性能MECHANICAL PROPERTIES OF WELDED METAL | |||||||||||||||||||
试验项目 | Rel/Rp0.2屈服强度（MPa） | Rm抗拉强度（MPa） | A伸长率（%） | 试验温度（℃） | KV2(J) | ||||||||||||||
GB/T Standard | ≥460 | 550-740 | ≥17 | -40℃ | ≥27 | ||||||||||||||
485 | 580 | 28 | 90 | ||||||||||||||||
作业条件OPERATING CONDITIONS | |||||||||||||||||||
直径Diameter [mm] | φ1.0 | φ1.2 | φ1.6 | ||||||||||||||||
电流Current [A] | 平焊Flat | 100-200 | 120-300 | 180-450 | |||||||||||||||
上立焊/仰焊V-Up&Overhead | 100-200 | 120-260 | 180-280 | ||||||||||||||||
下立焊Vertical Downward | 150--250 | 200-280 | 250-300 | ||||||||||||||||
包装PACKAGING | |||||||||||||||||||
5kg 15kg 盘装 Coil 也可以定制其他包装和规格Other packaging and other diameters: please consult us | |||||||||||||||||||
